For further specification please use the filter function.
The ZM18 family is a long-proven product line that is useful as a positioning aid in image processing applications.
The structured light laser series ZQ1 has been developed for the most demanding measurement applications in the market.
Due to automated production processes in which all optical components are purposefully aligned with a 14-axis robot, the ZX laser series sets new standards in lighting for image mehr erfahren
ZLP1 is a cost-effective entry to laser projection. It is the smallest laser projector in the Z-LASER ZLP family.
The battery-powered ZAT has been successfully used in the Belt Aligner Set for years and is a high-quality alternative to the previous bestseller ZA.
The ZLP2 is the high-end model of the ZLP family and offers maximum performance in laser projection.
Due to automated production processes in which all optical components are aligned with a 14-axis robot, the ZXS laser series sets new standards for illumination in image process mehr erfahren
Thanks to an automated production process in which all optical components are aligned with a 14-axis robot, the ZXS laser series sets new standards for illumination in image pro mehr erfahren
ZFSM fiber-coupled lasers are the perfect solution for applications with high-precision optical requirements.
ZM12 laser modules are equipped with a Ø 15mm laser head and an M12 thread, suitable for applications with limited installation volume, such as small sensors and measuring head mehr erfahren
With a boresight error of less than 0.8 mrad, the ZX laser is one of the most accurate lasers on the market.
The high-performance ZQ2 laser module was specially developed for surveying because strong, bright lines with an IR wavelength are required.
The LP-HFD2 is the successor of our proven LP-HFD laser projector.
The precision mount is suitable for all laser modules with an M12 thread.
Aluminum mount for lasers with a Ø 20mm diameter.
This small laser module is ideal for the textile industry, and is therefore mainly used for positioning applications in the textile sector.
This robust laser module for positioning tasks can be used in all industries where a highly visible crosshair with thin lines is needed.
The ZRG-F positioning laser is the only laser in a Ø40 mm casing that offers a green dot and line projection.
The adjustable circular laser facilitates many applications with its variable opening angle.
The ZD laser module can optionally display a line, dot, or cross projection.
The alignment laser Belt Aligner has proven itself to be a highly precise, easy-to-use, and sturdy alignment system a thousand times over.
The ZR Positioning Laser is a durable product with a casing diameter of 40 mm.
This small dot laser (with a diameter of just Ø 11 mm) is ideal for any positioning task.
The ZPT-F with it’s integrated high-voltage power supply is one of our long laser series.
Aluminum mount for laser modules with a 20 mm laser head.
Aluminum mount for laser modules with a 40 mm laser head. The mount is 360 ° rotatable and mountable on a Ø 20mm shaft.
Aluminum mount for laser modules with a 20 mm laser head. The mount can be tilted 60 °.
Plastic mount with ball head for laser modules with a 20 mm laser head. 180 ° turnable and tiltable.
Aluminum mount for laser modules with a laser head diameter of Ø 20 mm.
Aluminum mount for laser modules with M12 thread.
This aluminum precision mount is suitable for all laser modules with an M18 thread.
Connection cable with screw cap, straight, 4-wire. Available in 2m or 5m length. Longer cable lengths available as a shielded version (see KB4G)
Shielded connection cable with screw cap, straight, 4-wire.
Connection cable with screw cap, angled, 4-wire.
Linear adjustment device; Double-track roller unit.
Aluminum mount for lasers with M18 thread
Power supply for DIN rail in control cabinet with 24 VDC output voltage. Vin: 100 to 240VAC
Power supply for DIN rail in control cabinet with 5 VDC output voltage. Vin: 100 to 240VAC
Wall and ceiling mount.
Aluminum rail for the attachment of 4 lasers, in combination with brackets H2 and H3.
Aluminum frames for attaching several lasers, ideally for mounts with H2 and H3 slots.
Magnetic mounting block for holders H2 and H3, with extremely strong magnets.
Adaptor for connection between a WPS power supply and ZT, ZD or ZF lasers.
Distribution box for connecting up to 4 ZB, ZD, ZF or ZT lasers to a WPS power supply, with ON / OFF switch and operational LED.
2m extension cable for ZD Laser.
Power supply with Texas plug and 3.5 VDC output voltage for Europe and US/Japan, or UK plugs. Vin: 100 to 240 VAC
Power supply with M12 circular connector and 5VDC output voltage for Europe and US/Japan, or UK plugs
Power supply with Texas Socket and 3.5 VDC output voltage for Europe and US/Japan, or UK plugs.
Socket without cable for M18 laser. Available with straight or angled cable outlet.
